Description
In addition to the Titanium RS Muffler canister and tip, each kit includes a stainless-steel muffler mounting-band (to weld on mounting hangers), pre-welded titanium inlet pipe and 2-bolt Ti flange, as well as a matching composite gasket and stainless-steel 2-bolt flange (to adapt the kit to steel piping.) The kits are available in a 3.0″ (76mm) and 2.5″ (63.5mm) piping sizes. Our signature high quality, straight-through, universal RS racing sport muffler design offers exceptional flow with a clean, yet aggressive exhaust note. And with the RS Tri-bolt removable Tip, optional RS inner tip silencers and tips can be purchased separately for even more customization.
With the included pre-welded Titanium 2-bolt flange and additional stainless-steel flange and stainless steel muffler cansister mounting bracket, you do not have to be able to weld Titanium to have a custom Titanium muffler, exhaust system. Just weld onto the provided flange and canister mounting bracket.
Specification:
Muffler Type: 140mm Round RS Titanium
Type: Straight-through
Inlet / Outlet : 63.5mm (2.5″) 2-bolt flange
Dia.: 140mm (5.5″)
Length: 300mm (11.8″)
Surface: brunt-Titanium brushed finish, with embossed GPP logo
Tip Type: Removable Single-wall Titanium with GReddy Logo with Tri-bolt mounting
Dia.: 105mm (4.1″)
Length: 120mm (4.7″)
Surface: brunt-Titanium brushed finish, with laser-etched GPP logo
Piping Extension: L38mm (1.5″)
+ 2.5″ piping at the back of the muffler, with a pre-welded 2.5″ 2-bolt Titanium flange
Included Hardware:
Additional un-welded stainless-steel 2.5″ 2-bolt flange (to adapt to steel or stainless steel piping)
One metal composite exhaust gasket 2.5″, nuts and bolts (to connect the titanium flange to the stainless steel flange)
A stainless-steel muffler canister mounting band. (to weld on steel or stainless steel muffler mounting hangers)
Note(s):
Requires welding (and cutting) for mounting and attaching piping
Other Part Numbers:
Greddy #gre11008525
